片冰機系統介紹

科美斯制冰機生產的片冰厚薄均勻、光潔、干燥，適用于超級市場、商業中心、購物廣場、海鮮酒樓、食品加工等海鮮、鮮肉、肉制品的降溫及保鮮，使產品保持新鮮效果。由于片冰表面干燥及干爽避免了劃傷魚品表面的可能，保持了下層海鮮的透氣性，保證了產品原有風味，防止產品脫水缺氧帶來的損傷。

Commercial flake ice systems:
   The flake ice is produced by COLDMAX that is applicable for  supermarkets, commercial centers, shopping malls, seafood restaurants, food processing

Where use flake ice to cool the temperature of seafood, meat products to ensure the fresh products effect due to its thickness uniformity, smooth, drying so that it’s definitely reduced the possibility of fish surface being scratched, maintaining the air permeability of inner seafood, preventing product from injuring caused by dehydration and hypoxic to guarantee the product original flavor.

工業片冰系統

科美斯片冰機在食品加工行業廣泛應用，食品高溫殺菌后，經過冰水混合快速冷卻，避免細菌滋生，保持產品原有風味； 在現代化工、染料工藝中，偶氮顏料的重氮化反應，偶合反應中，采用加冰控溫工藝，可有效控制重氮鹽的分解；在香腸生產的滾揉和輾拌過程中，由于高速旋轉的滾揉桶與配料的磨擦而產生的高溫，既助長了細菌的滋生，又改變了肉色與口感，而且會造成脫脂（肥肉溶化）使生產的香腸細菌的超標，色澤暗淡，口感較硬，而且油膩。當片冰被混合到香腸的配料中時，會獲得快速冷卻和理想的濃度，保持產品的色澤與口感，防止脫脂，提高衛生標準。

Industrial flake ice system:

COLDMAX the ice flakers is widely used in food processing industry, after the food have been finished high-temperature sterilization, it’s needed the ice water mixture to cool rapidly to avoid   bacterial breeding and keep the product original taste; in the modern chemical industry, dye process, the azo pigments of the diazotization reaction, coupling reaction, the use of ice temperature control process can be effectively contained in the decomposition of diazonium salt; in the process of producing sausage rubbing and rolling, as a result of high-speed rotation of the roll barrels and ingredients rubbing and friction generated heat which contributed to the breeding of germs and changed the color and texture, but will also cause skim (fat melting) to enable the production of excessive bacteria sausage, dim color, texture hard, and greasy. When the piece of ice was mixed ingredients in the sausage will be given the rapid cooling and the desired concentration, to maintain the color and texture fresh and improve health standards.

混凝土片冰系統

a混凝土應用

大型水電大壩、核電混凝土、高速鐵路、高層建筑基礎大體積的澆注需要采用溫控混凝土。混凝土在養護過程中隨著水化熱的釋放，混凝土內部強度逐漸增大，這種現象對于小型混凝土結構并不重要，但是對于需要澆注大量混凝土的水壩工程具有特別意義。在養護期間，水化熱使混凝土的溫度升高25℃，導致混凝土體積增大，而養護過后，混凝土溫度下降，體積減小，這一過程通常會造成水壩出現裂縫。因此混凝土的初始澆注溫度應該很低，以保證養護期間混凝土的最高溫度不能超過設計單位的限定溫度。雖然不同的國家，不同的工地對混凝土澆注溫度的要求不同，從7℃到最高達15℃。但是每個工程都需要配置完善的混凝土制冷系統。而其中加片冰是最有效的預冷方式，每10kg片冰可降低一立方混凝土溫度大約1.2℃～1.4℃左右。

Concrete flake ice system：

a :Application in concrete mixing works:

Temperature-controlled concrete is used to build large-scale hydroelectric dams, nuclear power plant concrete, high-speed rail, grout large-scale bases of high-rise buildings. In the course of maintenance, the internal intensity of concrete increases gradually with the release of water-changed heat, which is not important for small-sized concrete structures but especially significant for the dyke projects that require the grouting of a large amount of concrete. In the course of maintenance, water-changed heat raises the temperature of concrete by 25℃, causing its volume to expand. However, after maintenance, the temperature of concrete falls down and its volume reduces. The above course often brings about cracks in dykes. Therefore, the initial grouting temperature of concrete should be low enough to ensure that the highest temperature of concrete during maintenance does not exceed that determined by design units. Although the requirements for concrete grouting temperature vary from country to country and from construction site to construction site within the range of 7℃ to 15℃, every project needs installing with complete concrete refrigerating systems. Adding flake ice is the most effective pre-cooling way, each 10kg flake ice may reduce approximately 1.2℃ to 1.4℃ for one cube of concrete.

b自動儲冰及送冰系統

我們潛心研制的混凝土降溫系統，包括自動儲冰庫、螺旋輸送裝置、氣體輸送系統、自動計量系統、自動監控系統等。其中自動儲冰庫是送冰系統最主要的部分。傳統的耙冰式儲冰庫，因?yàn)楸抑荒軓纳喜块_始把冰耙出，所以下部的冰在庫內停留的時間較長，容易發生強固的凍結，無法用冰耙清除出庫。履帶式自動輸送裝置貯冰庫就是為了解決這個“強固結冰層”的問題而開發的最新銳設備。冰庫底部全體形成履帶式輸送帶，可整體向前方移動，把冰輸送到出口處的螺旋輸送部分。這樣就不存在下部的冰在庫內長期停留的問題，也就不會發生強固凍結。

Automatic ice storage and ice delivery system:

We dedicated ourselves to the development of concrete cooling system, including automatic storage device, spiral conveyor, pneumatic delivery system, automatic metering system and monitoring systems. Automatic storage device is the most significant part in the whole concrete cooling system. In traditional-style ice storage systems, the raker only started to rake up the ice from upper part of the ice, so the lower part of the ice in the hangar will stay still and are prone to lump, ice rake can not remove the lump of bottom. Tracked automatic transmission storage device is developed to solve the "strong lump ice" problem. Crawler at the bottom of the formation of the whole conveyor belt will continues take the ice hill make overall movement and transport the ice to the exit part of the spiral conveyor. Ice will not make long-term stay in the bottom, so strong freeze will not happen.

c氣送系統
我們的氣體送冰系統可以利用高壓氣體通過管道把冰輸送到遠距離甚至高處的目的地。應用范圍非常廣泛。如：保鮮行業，系統可直接把冰送到捕魚船和載魚船等所需要冰的場所；在化工場內，系統與計量裝置并用，可以簡單、準確地把所有量的冰輸送到需要進行冷卻降溫的化學反應爐內。

Pneumatic delivery system:

Our pneumatic delivery system can transport flake ice to remote destinations and even height place by making use of high-pressure cool gas in pipeline. This system has a wide range of applications, such as: food or aquatic preservation, flake ice can be sent directly to the fishing vessels which need to place ice by this system; in the chemical field, the system and metering devices can transport a request volume of flake ice accurately to the chemical reactor which need cooling and temperature control .

蒸發系統

片冰蒸發器采用固定靜止立式設計，即內刮制冰方式，螺旋冰刀在內壁逆時針運行，減少了冰刀與蒸發器內壁磨損，密封性高，有效防止制冷劑泄漏。蒸發器采用優質304不銹鋼材質，全自動氬弧焊接技術，冰刀采用304不銹鋼材質，洗床一次脫落成型，美觀大方。蒸發器設計壽命高達10年以上！

Evaporating System:

Flake ice evaporator use the horizontal motional design, screw scraper circling counterclockwise in the inner of evaporator, reducing the friction between scraper and evaporator, high air proof and leakage avoided. Evaporator using high-quality 304 stainless steel material and automatic argon-arc welding, ice screw scraper also using 304 stainless steel material and one time abscission molding, good looking and generous. Evaporator designed life-span for more than ten years.

海水制冰系統

科美斯海水片冰機運用不銹鋼、防腐蝕鋁合金、表面特殊處理合金的精工鑄造，直接放置于漁船上，利用海水直接制冰，落入般倉，船舶的負載量可大大減輕，燃料費用也可大幅節約。我們的片冰設備傾斜角度在35度以內，可保持水循環而不溢出且正常使用。占地面積小、噪音低、節能環保，可根據用冰量選擇您所需要的機型。

Sea water ice making system 片冰機,制冰機,工業制冰機,商業制冰機,制冰系統

COLDMAX seawater flake ice makers using stainless steel, anti-corrosion,  aluminum alloy, installed directly on the ship and using sea water to make ice, the ice falling down into cabin, those designs can reduce the ship’s burden, the expenses of oil consumption can cut down heavily. Our equipments keep angle within 35 degrees can   maintain the water circulation without overflowing, making ice normally. The advantages of machines are less occupation, low noise, energy saving and environment protection, choosing machines depend on your ice consumption.
